Conjure Standard 8K Resin Easy Print High Precision 3D Printing Liquid Standard Photopolymer Resin for LCD DLP 3D Printing for 3d printers
Conjure standard 8K is easy to print and get the best details for miniatures, and compare with first-generation standard resin it has better performance in toughness and durability.
Also bought together
- Reviews ( 0 )
- Additional information
Experience Exceptional Performance
Upgraded Strength and Durability
Why Slate Grey?
Slate grey is carefully selected from dozens of colors, aiming to bring vivid visual enjoyment to photography and make you experience perfect visual excellence.
Conjure series resin general setting
|Standard Resin||Functional Resin|
|Resin Type||Standard 8K||Rigid||Tough||Sculpt|
|Layer Height (mm)||0.05||0.05||0.05||0.05|
|Bottom Layer Count||6||6||6||6|
|Bottom Exposure Time(s)||35||35||35||35|
|Transition Layers Count||6||6||6||8|
|Bottom Lift Distance(mm)||6||8||8||8|
|Bottom Retract Distance(mm)||6||8||8||8|
|Bottom Lift Speed||180 mm/min 3 mm/s||180 mm/min 3 mm/s||180 mm/min 3 mm/s||60 mm/min 1 mm/s|
|Bottom Retract Speed||240 mm/min 4 mm/s||240 mm/min 4 mm/s||240 mm/min 4 mm/s||150 mm/min 2.5 mm/s|
|Lifting Speed||180 mm/min 3 mm/s||180 mm/min 3 mm/s||180 mm/min 3 mm/s||180 mm/min 3 mm/s|
|Retract Speed||240 mm/min 4 mm/s||240 mm/min 4 mm/s||240 mm/min 4 mm/s||180 mm/min 3 mm/s|
|Light-off Delay (s)||0~2s base on print size||0~3s base on print size||0~3s base on print size||0~3s base on print size|
CHITUBOX did quite a few tests and create the troubleshooting knowledge for users, take a look here if you meet a failed resin printing.
3D Printing Workflow
Make sure to wear nitrile gloves anytime you intend to handle liquid resins.
1. Check the model
Make sure to prepare your model well, to not get a failed print, you should check the orientation, dig hole, and support settings.
CHITUBOX has some great tutorials to explain how to add support
2. Printing profile settings. (exposure time, lift speed, etc.)
Your local printing environment and resin setting greatly affect the final print quality. Conjure series resin requests a temperature of 25-30 ℃.
Conjure resin printing profile guide, Click here
You can also download the exposure test file to get the best settings for your printers. Click here
3. Check printer status before printing
3.1 Make sure your vat is clean,(no extra piece in the vat, or it will affect the quality). there is a video by Nerdtronic Why Resin 3D Prints Fail
3.2 Make sure your plate leveling well, for normal resin, it is easy to print, The Conjure series resin especially for the sculpt resin has a higher viscosity, you have to level the bed very well before printing, It shallow penetration depth makes the adhesion between layers not very strong. (For bigger printers the leveling is more important)
3.3 Add more lifting distance and reducing the lifting speed will help to get better results.
4. Shake the resin before use
You need to shake the bottle for a few minis if your resin is not used in a long time.
5. Clean the prints
It is better to clear the resin before post-curing because the chemical reaction is not completed during the first printing. There is uncured resin left on your prints.
We recommend using Ethanol or IPA and a painter brush (or any brush made of hair) to remove uncured resins. Ensure the prints are cleaned well if you have a wash station.
For some complex print, an ultrasonic cleaner is the best choice to clean it.
6. Dry and post-curing
Dry the prints before curing them, and use 395~405nm UV light for about 60s to cure them. If you need more time to cure the prints, maybe your prints are not cleaned well.
7. Putty and Paint to make the prints more durable
The resin material is not that good in durability compared to the filament. The humidity and light affect it even if it is post-cured.
Advantages of putty:
- Color anti-interference ability, cover the original color of the model parts to prevent color deviation.
- Easy to reflect the details after putty base to facilitate the inspection of surface defects and textures.
- The putty base has stronger adhesion to the paint to prevent paint loss.
8. Frequently asked printing issue
We also write many articles on CHITUBOX website to help you understand better what printing issue you may meet, and why it happens.
You can learn more detail here:
Grey, White, Black
China, USA, EU( UK include), Russia
